Bosch FPA-5000 System Description

Modular Fire Panel Technical Data | en 159
Bosch Sicherheitssysteme GmbH System Description F.01U.028.089 | 8.0 | 2011.07
Installation of the device is described in Section 4.14 FMR-5000 Remote Keypad, page 134.
7.4.3 FSP-5000-RPS Programming Software
The following minimum system requirements are defined for the FSP-5000-RPS Programming
Software:
– Operating system: Windows XP, Vista, or 7 (Windows 64 bit operating systems are not
supported).
In the case of Windows XP, Service Pack 3 is required.
– Hard disk: At least 1 GB storage capacity.
– RAM: At least 500 MB.
7.5 Functional Modules
The functional modules have the following technical specifications in common:
Alternative technical data is listed for the individual modules.
7.5.1 ANI 0016 A Annunciator Module
Installation of the power supply unit is described in Section 4.9.2 ANI 0016 A Annunciator
Module, page 109.
7.5.2 BCM-0000-B Battery Controller Module
Space required (H x W x D) 280 x 340 x 87 mm
Weight approx. 3 kg
Permissible operating temperature -5 °C to 50 °C
Permissible storage temperature -20 °C to 60 °C
Relative humidity Max. 95 % non-condensing
Housing material and color ABS plastic, satin finish, anthracite, RAL 7016
Safety standards EN 60950
Protection class IP 30
Display elements 16 red LEDs, 16 yellow LEDs
Input voltage 20 V DC to 30 V DC/5 V DC ± 5 %
Maximum current consumption
– Standby mode (all LEDs off) 6 mA
– In case of alarm (all LEDs on) 26 mA
Space required (H x W x D) approx. 127 x 96 x 60 mm
Weight approx. 206 g
Input voltage 20.4 V to 30 V
Current consumption at 23 V DC
– Standby operation 25 mA
–Fault 40mA
Permissible battery capacities
– with 2 batteries 24 to 26 Ah, 36 to 45 Ah
– with 4 batteries 48 to 52 Ah, 72 to 90 Ah
Maximum current

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
