Modular Fire Panel Product Description | en 13
Bosch Sicherheitssysteme GmbH System Description F.01U.028.089 | 8.0 | 2011.07
2.3 FMR-5000 Remote Keypad
The FMR-5000 Remote Keypad can be used to perform the same operating procedures as the
panel itself, enabling a networked system to be operated decentrally.
Power can be supplied by the panel or an external power supply unit such as the FPP-5000.
The easy-to-install housing was designed for tilted installation and for surface or flush wall
mounting.
Figure 2.4 FMR-5000 Remote Keypad
Information on installing the Remote Keypad can be found in Section 4.14 FMR-5000 Remote
Keypad, page 134.
The technical data can be found in Section 7.4.2 FMR-5000 Remote Keypad, page 158.
Position Description
1 Touch screen
2 Membrane keys
3 LEDs for displaying the operating status
4 Key switch
2
3
4
1
