4.10 Cable Sets
Overview
There are various cable sets available for connecting the central components.
All cable sets are supplied with installation instructions ex works. You can also find the
installation instructions at www.boschsecurity.com by searching for the type designation of
the product. The document numbers of the installation instructions can be found in the footer
on every page of the document.
The table below shows the instructions available.
4.11 Monitoring auxiliary power according to EN 54-13
Auxiliary power supplies to the following modules can be monitored for creeping short
circuits and creeping wire breaks: LSN 300, LSN 1500, and BCM-0000-B (when using FPP-
5000-TI13). A creeping short circuit is detected by these modules. An FPP-5000-TI13 forwards
the faults detected and reported by the BCM-000-B to the panel. Use additional 4-wire end of
line elements to monitor for creeping wire break.
Procedure:
1. Monitor with 4-wire end of line element:
– On stub cabling, terminate the exposed end of an AUX line with an FLM-420-EOL4W
– Insert an FLM-420-EOL4W as the last element of an LSN ring or of a stub
– Use an FLM-320-EOL4W for the conventional zone of a conventional zone module or
a FLM-420-CON/4
2. Activate EN 54-13 compliant operation.
Type designation Connection of ... ... to Document number
CBB 0000 A
1)
BCM Battery Controller
Module
Battery pair F.01U.003.099
CPA 0000 A MPC Panel Controller FMA-AT 2000-IP/-ISDN/-GSM, ENO 0000 B F.01U.003.343
CPB 0000 A BCM Battery Controller
Module
UPS Universal Power Supply F.01U.003.098
CPR 0001 A MPC Panel Controller RLE 0000 A Junction Board F.01U.003.342
CRP 0000 A MPC Panel Controller MPC Panel Controller (Redundant) F.01U.003.097
1) Required for power supply in a separate power supply housing. Compared to the enclosed standard cable sets,
this cable set has a longer connecting cable to the battery.
NOTICE!
In the installation instructions for the CPA 0000 A Cable Set: Please refer to the programming
instructions for the FMA-AT 2000-IP/-ISDN/-GSM.
NOTICE!
According to EN 54-13, no branch wiring (T-tapping) is permitted for auxiliary power supplies.

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
