Bosch FPA-5000 System Description

160 en | Technical Data Modular Fire Panel
F.01U.028.089 | 8.0 | 2011.07 System Description Bosch Sicherheitssysteme GmbH
Installation of the power supply unit is described in Section 4.9.3 BCM-0000-B Battery
Controller Module, page 110.
7.5.3 CZM 0004 A 4 Zone Conventional Module
Installation of the power supply unit is described in Section 4.9.4 CZM 0004 A 4 Zone
Conventional Module, page 113.
–of the module Max. 6A
–to panel rails
PRS 0002 A/PRS 0004 A)
Max. 6 A
– for switch outputs Max. 5.6 A (2 x 2.8 A cannot be connected in
parallel)
Maximum load of fault outputs BAT
FAULT, AC FAULT and collective fault
0 V/0 - 20 mA
Maximum battery resistance (fault
threshold)
430 mΩ
Voltage outputs
– 2 switchable outputs +24 V (20.4 - 30 V), 2.8 A, battery buffered
(programmable)
Display and operating elements
– 1 green LED Mains power on
– 3 yellow LEDs Mains fault /fault in battery 1/fault in battery 2
– 1 button LED test, start charging manually, reset switch
outputs
Space required (H x W x D) approx. 127 x 96 x 60 mm
Weight 193 g
Permissible operating temperature -5 °C to 50 °C
Permissible storage temperature -25 °C to 85 °C
Input voltage 20 V DC to 30 V DC
5 V DC ± 5%
Maximum current consumption
– Standby mode (all 4 zones) 65 mA (at 24 V DC)
– In case of alarm (all 4 zones) 65 mA + 100 mA per zone (at 24 V DC)
Outputs (OUT 1–OUT 4)
– Maximum output voltage 20 V DC ± 5%
– Maximum output current 100 mA ± 10% per zone
– Max. line resistance 2 x 25 Ω per zone
Auxiliary power supply (AUX1–AUX4)
– Max. output current (total of all 4
outputs)
230 mA
Space required (H x W x D) approx. 127 x 96 x 60 mm
Weight without packaging Approx. 135 g
Operating and display elements 8 LEDs (4 x red, alarm/4 x yellow, fault)
4 keys (LED test)

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
