Modular Fire Panel Installation | en 141
Bosch Sicherheitssysteme GmbH System Description F.01U.028.089 | 8.0 | 2011.07
Figure 4.95 FMR-5000 surface mounting; dimensions in mm
091
340
220
240
082
2,78
54
6
11
4x
(∅ 8x40mm)
∅ 5x50mm
PZ2
S8
4x
∅ 5x50mmPZ2
4x
∅ 8mm
PZ2
50
05
2,4
