Modular Fire Panel Product Description | en 19
Bosch Sicherheitssysteme GmbH System Description F.01U.028.089 | 8.0 | 2011.07
Equipment Limits
The table below shows the maximum number of:
–Modules
– Panel rails (short PRS 0002 A, long: PRD 0004 A)
The table below shows the maximum number of:
– Panel controllers
– UPS power supply units
– Batteries
Installation Types
Various types of installation are possible:
– Surface mounted
– Installation in 482.6 mm (19") racks
For surface mounting, the housing is mounted directly on the wall. For installation in
482.6 mm (19") racks, the FRK 0019 A installation kit is used.
The housings have pre-formed cable bushings.
Front Doors
The housings can also be equipped with transparent front doors. The doors are made of
impact-resistant plastic and are available in two sizes (each with a lock on the left or right).
The technical data for the housings can be found in Section 7.3.2 Housings for Wall Mounting,
page 154.
Housing type Modules PRS 0002 A PRD 0004 A
HCP 0006 A 6 1 1
HBC 0010 A 10 1 2
HBE 0012 A 12 - 3
PSS 0002 A - - -
PSB 0004 A - - -
DIB 0000 A - - -
Housing type MPC UPS power supply
units
Batteries
HCP 0006 A 1 1 2 x 28 Ah
HBC 0010 A 1 1 2 x 28 Ah
HBE 0012 A - 1 2 x 28 Ah
PSS 0002 A - 1 2 x 28 Ah
PSB 0004 A - 1 4 x 28 Ah
DIB 0000 A - - -
Housing type Front door, lock left side Front door, lock right side
HCP 0006 A FDT 0003 A FDT 0000 A
HBC 0010 A FDT 0002 A FDT 0001 A
HBE 0012 A FDT 0002 A FDT 0001 A
