Bosch FPA-5000 System Description

60 en | Installation Modular Fire Panel
F.01U.028.089 | 8.0 | 2011.07 System Description Bosch Sicherheitssysteme GmbH
Cable Bushings
Wall mounting housings have pre-punched cable bushings with the three most common
diameters (22 mm, 35 mm, 44 mm).
Figure 4.7 Wall mounting housing cable bushings
NOTICE!
Carefully punch out the pre-punched hole for the cable entry and fit a suitable cable grommet.
When inserting the cable into the housing, pierce a hole in the grommet with a pointed object,
do not cut.
HCP 0006 A
HBC 0010 A
HBE 0012 A
PSB 0004 A
PSS 0002 A
28.4
∅
28.4
∅
28.4
∅
28.4
∅
28.4
∅

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
