Modular Fire Panel Installation | en 63
Bosch Sicherheitssysteme GmbH System Description F.01U.028.089 | 8.0 | 2011.07
Installation Dimensions for PSF 0002 A and USF 0000 A with FSH 0000 A Mounting frame
Figure 4.10 Installation dimensions for PSF 0002 A and USF 0000 A [in mm]
267
292
280
292
3
440 15,5 236
13
25
145
452,5
455,5
3
91
236
12
