M710 User Manual 78
Label Types
Rollform PipeMarker
• For NA, tap
Set Graphics
. Skip to step 8.
• For EU, tap
Set Text
.
6. For EU, fill in the text screen.
•
Product Name:
Enter the specific chemical or substance that flows through the pipe. For
example, if the P
ipe Contents
on the previous screen was
Low hazard liquid
, the
Product
Name
here might be
Cold Water Return
.
•
Comment 1 (optional):
Enter additional text that should display on the label.
7. For EU, tap Set Graphics.
8. Fill in the graphics screen.
a. In the # of Graphics list, select the number of graphics to display on the label. You can
add up to four graphics per label. If ‘0’ is selected, proceed to step e.
b. In the Category list, select the hazardous materials system that you want to use graphics
from.
c. Tap Graphic #1 and then select the desired graphic.
d. If you specified more than one graphic, select the remaining graphics in the same manner:
tap the graphic number and then the graphic.
e. Press .
Tip: You can always go back to the previous screen by selecting the lower left button on the
screen (Set Text or Set Contents).
9. Tap OK. The label displays in a preview mode on the screen. Use the navigation keys to view
the contents of the entire label.
