Branson S83 - Ultrasonic Generator Models; Options

S83/85 Ultrasonic Generator Introduction
A40-064 Rev 0 Page 14
1.6.1 Ultrasonic Generator Models
Table 1 Ultrasonic Generator Models
Part Number Series Model Voltage
Nominal
Power level
Number of
elements
Standard Groupings
101-132-468 8300 S8325-12 120 VOLT
500W 12 1x12 or 2x6
101-132-469 S8325-12 230 VOLT
500W 12 1x12 or 2x6
101-132-471 S8325-18 "
750W 18 1x12 & 1x6 or 3x6
101-132-472 S8325-24 "
1000W 24 2x12 or 4x6
101-132-473 S8325-36 "
1500W 36 3x12 or 6x6
101-132-474 S8325-48 "
2000W 48 4x12 or 8x6
101-132-475 S8340-12 120 VOLT
500W 12 1x12 or 2x6
101-132-476 S8340-12 230 VOLT
500W 12 1x12 or 2x6
101-132-478 S8340-18 "
750W 18 1x12 & 1x6 or 3x6
101-132-479 S8340-24 "
1000W 24 2x12 or 4x6
101-132-480 S8340-36 "
1500W 36 3x12 or 6x6
101-132-481 S8340-48 "
2000W 48 4x12 or 8x6
101-132-482 8500 S8525-12 120 VOLT
500W 12 1x12 or 2x6
101-132-483 S8525-12 230 VOLT
500W 12 1x12 or 2x6
101-132-485 S8525-18 "
750W 18 1x12 & 1x6 or 3x6
101-132-486 S8525-24 "
1000W 24 2x12 or 4x6
101-132-487 S8525-36 "
1500W 36 3x12 or 6x6
101-132-488 S8525-48 "
2000W 48 4x12 or 8x6
101-132-489 S8540-12 120 VOLT
500W 12 1x12 or 2x6
101-132-490 S8540-12 230 VOLT
500W 12 1x12 or 2x6
101-132-492 S8540-18 "
750W 18 1x12 & 1x6 or 3x6
101-132-493 S8540-24 "
1000W 24 2x12 or 4x6
101-132-494 S8540-36 "
1500W 36 3x12 or 6x6
101-132-495 S8540-48 "
2000W 48 4x12 or 8x6
101-132-682 80kHz S8580-12 230V
500W 12 1x12 or 2x6
101-132-683 " S8580-18 "
750W 18 1x12 & 1x6 or 3x6
101-132-684 " S8580-24 "
1000W 24 2x12 or 4x6
101-132-685 120kHz S85120-12 "
500W 12 1x12 or 2x6
101-132-686 " S85120-18 "
750W 18 1x12 & 1x6 or 3x6
101-132-687 170kHz S85170-6 "
250W 6 1x6
101-132-688 " S85170-12 "
500W 12 1x12 or 2x6
1.6.2 Options
Table 2 Generator Options
Part Number Type Description
101-063-347 Rack mount kit
101-063-503 I/O KIT OEM ON/OFF with status indication
101-063-561 I/O KIT FULL FEATURE, S8500 only
STD-392-317 I/O KIT OEM ON/OFF with external interlock
STD-410-901 TIMER 0-60 Mechanical Timer
