3.5 Matching Ultrasonic Equipment
Compare the model numbers on all equipment connected to the ultrasonic power supply. Figure
3-2 shows the labels that contain the model numbers.
Figure 3-2 Comparing Model Numbers
Figure 3-3 Translating Model Numbers
Immersible
Transducer
Ultrasonic
Tank
Ultrasonic Power
Supply
FC
CB
SB
EB
Number of Elements
Operating Frequency
Size of Immersible Transducer
Type of Immersible Transducer
1012
25
- 40
-12
C(H)
C Series tank (H-heated)
Operating Frequency
Number of Elements
Number of Elements
Series 83 or 85 Power Supply
Operating Frequency (kHz)
1012
25
40
80
120
- 170
-12
25
40
80
120
170
S83
S85
-12
Interior size of tank (inches, L to R, F to B)
Note: Use 40 kHz transducer with 80, 120 and 170 kHz generators.
