Branson S83 - Wiring One FC Immersible Transducer (12-Elements Shown)

S83/85 Ultrasonic Generator System Installation
A40-064 Rev 0 Page 53
5.8.4 Wiring One FC Immersible Transducer (12-elements shown)
Figure 5-17 Wiring One FC Type Immersible Transducer
ID Label
RF Cable
S8XXX − XX
J1
Assembly
S8000 RF Cable
Wiring Diagram
Transducers
Immersible
(GRN/YEL)
(BLK)
J1
1
3
2
J1
−
+
(RED)
(BLK)
Flexible Overbraid Hose from
FC type Immersible
RF+ (RED)
RF− (BLK)
GND (GRN/YEL)
J1
(RED)
1 2 3
Note: After installing, test grounds and continuity according to local codes.
