S83/85 Ultrasonic Generator Installation
A40-064 Rev 0 Page 22
3 Installation
3.1 Installation Overview
This section contains a sequence of tasks you must follow to ensure proper installation of your
ultrasonic power supply and ultrasonic tank. These tasks include:
1. Unpacking the ultrasonic power supply.
2. Choosing a suitable location for the ultrasonic power supply.
3. Matching ultrasonic equipment (ultrasonic power supply to tanks and immersible
transducers).
4. Connecting the ultrasonic power supply.
5. Installing an ultrasonic tank.
3.2 Unpacking the Ultrasonic Power Supply
Unpack the ultrasonic power supply as follows:
Step Action
1 Unpack the ultrasonic power supply as soon as it arrives, using
normal precautions to prevent damage.
2 Inspect the controls, indicators, and surface for damage.
3 Make sure that all switches are off.
Note: If damage occurred, notify the shipping company immediately. Retain packing materials for
inspection.
3.3 Electrical Requirements
Standard line voltage: 187-253 VAC 50/60 Hz
108-132 VAC 50/60 Hz (120 Volt models)
Table 3 Current Draws (Amps)
Elements 208V 230V 120V
12 2.2 2 4
18 3.3 3
24 4.4 4
36 6.6 6
48 8.8 8
3.4 Locating the Ultrasonic Power Supply
Locate the ultrasonic power supply according to the following guidelines:
• Make sure the ambient air temperature where you locate and operate the ultrasonic power
supply does not exceed 45˚C (113˚F).
• Make sure air flow to the fan is not obstructed.
• Locate the ultrasonic power supply in a electrically non-conductive atmosphere.
• Make sure to locate the ultrasonic power supply in an area free from water spray, splashing,
and dripping.
• Ground the ultrasonic power supply receptacle in accordance with local building codes.
