S83/85 Ultrasonic Generator Installation
A40-064 Rev 0 Page 26
3.7 Ultrasonic Tank Installation
3.7.1 Overview
This section contains instructions for installing and operating a Branson ultrasonic tank with the
S8000 ultrasonic power supply. The following tables contain model numbers and part numbers
for unheated and heated ultrasonic tanks.
Table 4 Ultrasonic Tanks - Unheated
Model Part No. –
Chromated
Part No. – Bright
Annealed Finish
C1012-25-12 101-908-202 101-908-228
C1216-25-18 101-908-206 101-908-227
C1620-25-24 101-908-210 101-908-223
C2024-25-36 101-908-214 101-908-219
C1012-40-12*@& 101-908-200 101-908-229
C1216-40-18*@ 101-908-204 101-908-226
C1620-40-24* 101-908-208 101-908-221
C2024-40-36 101-908-212 101-908-218
Table 5 Ultrasonic Tanks - Heated
Model Part No. –
Chromated
Part No. – Bright
Annealed Finish
CH1012-25-12 101-908-203 101-908-230
CH1216-25-18 101-908-207 101-908-225
CH1620-25-24 101-908-211 101-908-222
CH2024-25-36 101-908-215 101-908-216
CH1012-40-12*@& 101-908-201 101-908-231
CH1216-40-18*@ 101-908-205 101-908-224
CH1620-40-24* 101-908-209 101-908-220
CH2024-40-36 101-908-213 101-908-217
* May be operated with 80 kHz generator
@ May be operated with 120 kHz generator
& May be operated with 170 kHz generator
To Next Page
