Branson S83 - Mounting and Wiring SB Type Immersible Transducers

S83/85 Ultrasonic Generator System Installation
A40-064 Rev 0 Page 66
5.10.3 Mounting and Wiring SB Type Immersible Transducers
Figure 5-30 Wiring SB Junction Boxes
ultrasonic
RF cable to
power supply
EB/SB style
junction boxes
transducers
immersible
SB−Type
