Branson S83 - Figure 7-7 Analog Input - 1 Point

S83/85 Ultrasonic Generator Options
A40-064 Rev 0 Page 88
Figure 7-7 Analog Input - 1 Point
AMPL
AMPL
ISOLATED
SUPPLY
COM
IN
CONTROL
+
VOLTS
INTERNAL
SUPPLY
ANALOG
ISOLATOR
100K
INPUT SPECIFICATIONS
TYPE OF DEVICE 0−10VDC VOLTAGE SOURCE
ANALOG ISOLATIONISOLATION
100K OHM − VOLTAGE INPUTINPUT IMPEDANCE
_
Figure 7-8 Analog Output - 2 Points
OUTPUT IMPEDANCE
TYPE OF DEVICE
ISOLATION
COM
OUT
0−10VDC VOLTAGE SOURCE/
100 OHM − VOLTAGE OUTPUT
OUTPUT SPECIFICATIONS
BUFFER
AMPL
ANALOG
ISOLATOR
AMPL
5mA − VOLTAGE
MAX.OUTPUT SOURCE
(0−20mA) OR (4−20mA)
250 OHM − CURRENT OUTPUT
20mA − CURRENT
ANALOG ISOLATION
CURRENT SOURCE
LOAD
R OUT
INTERNAL
SUPPLY
ISOLATED
SUPPLY
