S83/85 Ultrasonic Generator System Installation
A40-064 Rev 0 Page 44
5.6 Mounting Junction Boxes
FC-type and CB-type immersible transducers connect to the ultrasonic power supply through a
flange-mount junction box that contains mounting flanges on the bottom. Mount this junction box
on the outside of the tank wall or cleaning system framework near the immersible transducer.
If installing one or two FC- or CB-type immersible transducers, install a flange mount junction
box by following these steps:
Step Action
1 Select a location for the flange-mount junction box on the outwall of
the tank or framework.
2 If installing, measure and mark the four places for weld studs (Figure
5-8)
3 If installing on framework, drill 4 holes 3/16 inches in diameter. If
installing on a tank, use #10-32 weld studs.
4 Mount and secure the junction box.
You use a master junction for connecting of three and four immersible transducers. Mount a
master junction box by following these steps:
Step Action
1 Select a location for the master junction box.
2 Measure and mark the four places for mounting the junction box
(Figure 5-8).
3 If installing on a tank wall, install weld studs – Never drill holes in
a tank. If installing on another surface, drill four holes 3/16 inches
in diameter.
4 Mount the master junction box to the tank or surface.
If mounting EB or SB immersible transducers, refer to the mounting instructions for EB or SB
immersible transducers.
