5.5 Junction Boxes
Junction boxes allow for connecting an array of immersible transducers to the ultrasonic power
supply. Figure 5-8 contains illustrations of each junction box style.
Figure 5-8 Junction Boxes
Weld Studs
(4 places)
Tank wall
Flange−Mount Junction Box
Master Junction Box
Tank wall
4
3
4
IN
(4 places)
Weld Studs
EB/SB−Type Junction Box
Refer to Configuration Diagrams which outline how the three styles of junction boxes are used.
