S83/85 Ultrasonic Generator System Installation
A40-064 Rev 0 Page 56
5.8.7 Wiring Four FC Immersible Transducers (48 elements shown)
Figure 5-20 Wiring Four FC Type Immersible Transducers
(GRN/YEL)
Wiring Diagram
To Immersibles
Flexible Conduit (4)
SS Overbraid
J1
S8XXX − XX
GND (GRN/YEL)
RF− (BLK)
RF Cable
ID Label
2
RF+ (RED)
Immersible
Transducers
−
+
3
2
(BLK)
− −
(RED)
+ +
1
3
S8000 RF Cable
Assembly
(RED)
(RED)
1
J1
(BLK)
J1
(RED)
J1
−
+
(RED)
(BLK)
(BLK)
(BLK)
RED
JUMPER
BLACK
JUMPER
Note: After installing, test grounds and continuity according to local codes.
