5.9.5 CB-Type Transducers – 24-Element
Figure 5-25 Wiring 2 CB Type Immersible Transducers
ID Label
RF Cable
S8XXX − XX
J1
Assembly
S8000 RF Cable
Wiring Diagram
−
Transducers
Immersible
+
(GRN/YEL)
(BLK)
J1
1
3
2
J1
−
+
(RED)
(RED)
(BLK)
(BLK)
RF Cables from
CB type Immersibles (2)
RF+ (RED)
RF− (BLK)
GND (GRN/YEL)
J1
(RED)
1 2 3
Note: After installing, test grounds and continuity according to local codes.
