S83/85 Ultrasonic Generator Options
A40-064 Rev 0 Page 97
7.5 Rack Mount Kit
The Rack Mount Kit consists of two brackets, handles and the hardware to mount them. Assemble
the handles to the brackets and mount the brackets onto the generator as shown using the hardware
provided with the kit. The mounting slots on the bracket will fit a standard 19 inch rack.
Caution: Do not use the rack mount kit to support the generator. Use a shelf or support rails
instead.
Figure 7-14 Rack Mount Kit
BRACKET
