Branson S83 - Page 87

S83/85 Ultrasonic Generator Options
A40-064 Rev 0 Page 87
Figure 7-5 Discrete Input - Sinking Input Type – 6 Points
INPUT SPECIFICATIONS
COM
IN
INPUT IMPEDANCE
TYPE OF DEVICE
ISOLATION
1K
NON−VOLTAGE CONTACTS
OR NPN OPEN COLLECTOR
+15V
ANALOG ISOLATION
ISOLATED
SUPPLY
1K OHM
ANALOG
ISOLATOR
FILTER
Figure 7-6 Discrete Outputs – Normally Open Contacts – 2 Points
30 mOHMS
5000VAC ISOLATION
RELAY CONTACT N.O.
RELAY ISOLATION
CONTACT RATING
OUTPUT IMPEDANCE
5.0A
24VAC OR VDC
TYPE OF DEVICE
COM
OUT
ISOLATION
OUTPUT SPECIFICATIONS
