S83/85 Ultrasonic Generator Operation
A40-064 Rev 0 Page 31
Figure 4-1 Operating US Switch S85
LED lit
Press key
Figure 4-2 Operating US Switch S83
Press key
LED lit
Press the U/S switch. The U/S power level will slowly ramp to the maximum setting determined
by: (a) the power level setting or (b) the external DC control voltage (in Remote position).
The S85 generator will display the power level on the bar graph.
