Brother DCP-8152DN User Manual

3-121
Confidential
10.4 T2 side cover R
(1) Remove the taptite bind B M4x12 screw from the front side of the T2 side cover R.
(2) Release the two front hooks, two top hooks and four bottom hooks, and remove the T2
side cover R from the LT unit.
Fig. 3-152
Hooks
Taptite bind B M4x12
Hooks
T2 side cover R
Hooks
LT unit
Hooks

Brother DCP-8152DN Specifications

General

Printer Type	Monochrome Laser Printer
Functions	Print, Copy, Scan
Print Resolution	Up to 1200 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet
Monthly Duty Cycle	Up to 50, 000 pages
Scanner Type	Flatbed with ADF
Optical Resolution	Up to 1200 x 1200 dpi
Copier Resolution	Up to 1200 x 600 dpi
Network Ready	Yes
Display	LCD
Weight	16.5 kg
Print Speed	Up to 40 ppm
Paper Input Capacity	250 sheets
ADF Capacity	35 sheets
Maximum Paper Size	A4
Maximum Copy Speed	Up to 40 cpm
