5-49
Confidential
2.4 Reset Developer Roller Counter
This function allows you to manually perform the same operation as when the toner cartridge
is replaced with a new one. The purpose of this function is to provide an error resetting
method in the event that the toner end display was not cleared because the new toner
cartridge was not detected by the machine for any reason.
<Operation Procedure>
Non touch panel models
(1) Open the front cover.
(2) Press the [Clear] button.
"Replace Drum? 1.Yes 2.No" is displayed on the LCD.
(3) Reset the counter as described below depending on the type of toner.
Starter toner: Press the [*], [1] and [0] buttons in this order.
Standard toner: Press the [*], [1] and [1] buttons in this order.
High yield toner: Press the [*], [1] and [2] buttons in this order.
Super high yield toner: Press the [*], [1] and [3] buttons in this order.
When the type of toner is not clear: Press the [*], [0] and [0] buttons in this order.
(Regarded as the same type as the toner previously set.)
"Accepted" is displayed on the LCD, and the machine returns to the ready state.
(4) Close the front cover.
Touch panel models when "no toner" is not
displayed
(1) Open the front cover.
(2) Press the [1] button.
"Reset Menu" is displayed on the LCD.
Press the [ ] or [ ] button to select
the toner cartridge to be reset, and
press the [OK] button.
(3) "Reset? Yes No" is displayed on the
LCD. Press the [Yes] button.
"Accepted" is displayed on the LCD,
and the machine returns to the ready
state.
(4) Close the front cover.
Touch panel models when "no toner" is
displayed
(1) Press the [Stop/Exit] button to return the
LCD to the standby display.
(2) Open the front cover and then close it.
(3) While "Please Wait" is displayed on the
LCD, open the front cover again.
(4) When "Cover is Open" is displayed on
the LCD, press the [1] button. "Reset" is
displayed on the LCD.
Press the [ ] or [ ] button to select
the toner cartridge to be reset, and
press the [OK] button.
(5) "Reset? Yes No" is displayed on the
LCD. Press the [Yes] button.
"Accepted" is displayed on the LCD,
and the machine returns to the ready
state.
(6) Close the front cover.
