Brother DCP-8152DN User Manual

3-4
Confidential
4. SCREW TORQUE LIST
Note:
• For verifying the shape of each screw, refer to "3.SCREW CATALOGUE" in this chapter.
Location of screw Screw type Q'ty
Tightening torque
N.m (kgf.cm)
T1 tray cover Taptite bind B M4x12 2 0.8±0.1(8±1)
Side cover L Taptite bind B M4x12 2 0.8±0.1(8±1)
Side cover R ASSY Taptite bind B M4x12 2 0.8±0.1(8±1)
Main shield cover plate Taptite cup S M3x8 SR 4 0.5±0.1(5±1)
ADF unit Taptite bind B M4x12 2 0.8±0.1(8±1)
Hinge ASSY L Taptite cup S M3x12 3 0.85±0.05(8.5±0.5)
Hinge support R Taptite cup B M3x10 1 0.5±0.05(5±0.5)
Hinge arm R Taptite cup B M3x10 3 0.5±0.05(5±0.5)
ADF separation pad holder Taptite cup B M3x10 1 0.5±0.05(5±0.5)
Upper ADF chute Taptite cup B M3x10 6 0.5±0.05(5±0.5)
Lower ADF chute Taptite cup B M3x10 3 0.5±0.05(5±0.5)
ADF earth harness Taptite cup S M3x8 SR 1 0.7±0.1(7±1)
Drive frame ASSY Taptite cup B M3x10 3 0.5±0.1(5±1)
ADF motor ASSY
Screw pan (S/P washer)
M3x6 DA
1
Legal model :
0.6±0.1(6±1)
1
A4 model :
0.35±0.05(3.5±0.5)
Control panel ASSY
(Touch panel model)
Taptite bind B M4x12 2 0.65±0.05(6.5±0.5)
Touch panel PCB harness
Taptite bind B M4x12
(Machine side)
10.8±0.1(8±1)
Screw pan (S/P washer)
M3x6 DA
(Panel PCB ASSY side)
10.7±0.1(7±1)
Panel PCB ASSY
(Touch panel model)
Screw pan (S/P washer)
M3x6 DA
20.7±0.1(7±1)
Touch panel plate
(Touch panel model)
Taptite cup B M3x10 7 0.5±0.05(5±0.5)
Control panel ASSY
(Non touch panel model)
Taptite bind B M4x12 3 0.65±0.05(6.5±0.5)
Document scanner unit Taptite bind B M4x12 5 0.8±0.1(8±1)
Document scanner top cover ASSY Taptite bind B M4x12 5 0.65±0.05(6.5±0.5)
NCU earth harness
(Low-voltage power supply PCB
ASSY side)
Screw pan M4x8 1 0.5±0.1(5±1)
NCU earth harness
(NCU PCB ASSY side)
Screw pan (S/P washer)
M3.5x6 DA
10.45±0.05(4.5±0.5)

Brother DCP-8152DN Specifications

General

Printer Type	Monochrome Laser Printer
Functions	Print, Copy, Scan
Print Resolution	Up to 1200 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet
Monthly Duty Cycle	Up to 50, 000 pages
Scanner Type	Flatbed with ADF
Optical Resolution	Up to 1200 x 1200 dpi
Copier Resolution	Up to 1200 x 600 dpi
Network Ready	Yes
Display	LCD
Weight	16.5 kg
Print Speed	Up to 40 ppm
Paper Input Capacity	250 sheets
ADF Capacity	35 sheets
Maximum Paper Size	A4
Maximum Copy Speed	Up to 40 cpm
