8. DISASSEMBLY FLOW CHART
Disassembly / Re-Assembly (second)
9.1 Duplex tray
5/5
9.2 Paper tray 1
5/5
9.9.3 ADF document
output support flap
5/5
9.9.4 Document sub
tray
5/5
9.39 T1 roller holder
ASSY
5/10
9.9.12 Drive frame
ASSY / Document feed
roller ASSY 1
35/50
9.9.13 ADF motor
ASSY
10/10
9.9.2 Hinge R
15/15
9.9.12 Document
ejection shaft
5/5
9.9.12 Document
ejection roller ASSY 1
5/10
9.9.14 First side
document hold
5/5
9.9.12 Lower ADF
chute
15/20
9.9.1 Hinge ASSY L
15/15
9.7 Side cover L /
Access cover
20/20
9.9 Main shield cover
plate
20/25
9.9 ADF unit
70/50
9.9.5 ADF cover ASSY
5/10
9.9.6 Gear cover
10/10
9.9.7 Document
separate roller ASSY
5/10
9.9.10 Document feed
roller ASSY 2
5/10
9.9.10 Upper ADF
chute
15/20
9.9.11 ADF cover/
document detection
sensor PCB ASSY / First
side document scanning
position sensor PCB ASSY
/ Second side document
scanning position sensor
PCB ASSY
30/30
9.9.8 ADF separation
pad spring / ADF
separation pad
Legal model
10/30
A4 model 10/10
9.9.9 Second side CIS
unit / Second side CIS
flat cable (duplex
scanning models only)
10/15
9.11.1 First side CIS
unit
10/30
9.8 Side cover R ASSY
20/20
9.5 MP cover ASSY
5/10
9.5 MP paper guide
ASSY
10/10
9.11.1 Document
scanner top cover
ASSY
20/20
9.16 NCU PCB ASSY
50/60
9.13 Wireless LAN
PCB ASSY
10/20
9.12 Joint cover
90/100
9.14 USB host PCB
ASSY
20/30
9.15 Speaker unit
20/30
9.11 Document
scanner unit
30/40
9.42 MP roller holder
ASSY / MP separation
pad ASSY / MP
separation pad spring
20/40
9.10 Panel cover /
Printed panel cover
5/5
9.10 Control panel
ASSY
15/25
9.10 Panel PCB ASSY
30/30
9.10 Touch panel plate
25/25
9.10 LCD / Touch panel
ASSY
5/5
9.10 Rubber key L
5/15
9.10 Rubber key R
5/5
9.10 Panel light guide
5/5
9.10 Panel cover
5/5
9.10 Control panel
ASSY
20/20
9.10 Panel PCB ASSY
20/20
9.10 Rubber key C
25/25
9.10 Rubber key L
5/25
9.10 Rubber key R
5/10
9.10 Caution lamp lens
/ Panel light guide
5/5
9.10 LCD cover / Back
light ASSY / LCD
15/15
Touch panel models
Non touch panel models

Brother DCP-8152DN Specifications

General

Printer Type	Monochrome Laser Printer
Functions	Print, Copy, Scan
Print Resolution	Up to 1200 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet
Monthly Duty Cycle	Up to 50, 000 pages
Scanner Type	Flatbed with ADF
Optical Resolution	Up to 1200 x 1200 dpi
Copier Resolution	Up to 1200 x 600 dpi
Network Ready	Yes
Display	LCD
Weight	16.5 kg
Print Speed	Up to 40 ppm
Paper Input Capacity	250 sheets
ADF Capacity	35 sheets
Maximum Paper Size	A4
Maximum Copy Speed	Up to 40 cpm
