Brother DCP-8152DN User Manual

2-11
Confidential
2.4 Block Diagram
Fig. 2-7
Wireless LAN
LVPS PCB
Main PCB
USB
function
DIMM
Eject sensor
PCB
Center thermistor
Side thermistor
Halogen-heater
Power switch
Fuser unit
(Wireless LAN model only)
Back cover
sensor
T1 clutch
Registration
clutch
Main motor
Main fan
MP-PE
sensor PCB
Regist front/
rear sensor
PCB
Front cover
sensor
Toner LED PCB
Laser unit
Relay front
PCB
HVPS PCB
T1 paper
feed sensor
Develop clutch
Duplex
solenoid
Toner sensor
PCB
Back-light PCB
Panel PCB
LCD
T2 paper
feed sensor
T2 relay PCB
T2 clutch
ADF cover
sensor PCB
Second side
document scanning
position sensor PCB
Toner sensor
New toner
sensor
Toner sensor
MP solenoid
ADF document
detection sensor
ADF cover
sensor
NCU PCB
Speaker
USB host
relay PCB
Internal
thermistor
Motor relay
PCB
First side
CIS unit
Second side
CIS unit
ADF unit
Document scanner
unit
Panel (5 line model)
Panel
(Color LCD model)
Panel PCB
Color LCD
ADF motor
Document
scanner motor
LT
connector
Touch panel
ASSY

Brother DCP-8152DN Specifications

General

Printer Type	Monochrome Laser Printer
Functions	Print, Copy, Scan
Print Resolution	Up to 1200 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet
Monthly Duty Cycle	Up to 50, 000 pages
Scanner Type	Flatbed with ADF
Optical Resolution	Up to 1200 x 1200 dpi
Copier Resolution	Up to 1200 x 600 dpi
Network Ready	Yes
Display	LCD
Weight	16.5 kg
Print Speed	Up to 40 ppm
Paper Input Capacity	250 sheets
ADF Capacity	35 sheets
Maximum Paper Size	A4
Maximum Copy Speed	Up to 40 cpm
