5-29

Confidential

1.3.19 Continuous print test (function code: 67)

This function is used to conduct paper feed and eject tests while printing patterns.

(1) Press the [6] and [7] buttons in this order in the initial state of maintenance mode.

"SELECT: K 100%" is displayed on the LCD.

(2) Refer to the table below (print pattern), and press the [ ] or [ ] button to select the

pattern you want to print. Then press the [OK] button. "SELECT: A4" is displayed on the

LCD.

(3) Refer to the table below (paper size), and press the [ ] or [ ] button to select the

paper size you want to use. Then press the [OK] button. "SELECT: TRAY1" is displayed

on the LCD.

(4) Refer to the table below (print type), and press the [ ] or [ ] button to select the tray

with paper set. Then press the [OK] button. "PAPER FEED TEST" is displayed on the

LCD, and printing of the test pattern starts using the selected conditions.

(5) When the [Stop/Exit] button is pressed, printing is stopped, and the machine returns to

the initial state of maintenance mode.

Print pattern

Paper size

Print type

LCD Description

SELECT: K 100% 100% solid printing (continuous printing)

SELECT: K 1% 1% intermittent pattern printing (500-page printing)

SELECT: K 5% 5% intermittent pattern printing (500-page printing)

SELECT: Lattice Lattice printing (continuous printing)

LCD Description

SELECT: A4 A4

SELECT: LETTER Letter

LCD Description

SELECT: TRAY1 Single-side printing from paper tray 1

SELECT: TRAY2 Single-side printing from paper tray 2

SELECT: MP Single-side printing from MP tray

SELECT: TRAY1 DX Duplex printing from paper tray 1

SELECT: TRAY2 DX Duplex printing from paper tray 2

SELECT: MP DX Duplex printing from MP tray

Note:

• Duplex printing only supports 5% intermittent pattern printing. Single-side printing

applies to other patterns even when duplex printing is specified.
