Brother DCP-8152DN User Manual

3-5
Confidential
Earth plate
*1
Taptite cup S M3x8 SR 1 0.7±0.1(7±1)
Taptite bind B M4x12
(Non touch panel only)
10.8±0.1(8±1)
Joint cover Taptite bind B M4x12 4 0.8±0.1(8±1)
USB host PCB ASSY Taptite bind B M4x12 2 0.8±0.1(8±1)
NCU unit Taptite bind B M4x12 2 0.8±0.1(8±1)
NCU shield cover
Screw pan (S/P washer)
3.5x6 DA
10.45±0.05(4.5±0.5)
NCU PCB ASSY Taptite cup S M3x6 SR 2 0.45±0.05(4.5±0.5)
Main PCB ASSY Taptite cup S M3x8 SR 6 0.5±0.1(5±1)
Fuser unit line cover R Taptite bind B M4x12 1 0.8±0.1(8±1)
Fuser unit line cover L Taptite pan B M4x14 1 0.8±0.1(8±1)
Fuser unit Taptite pan B M4x14 1 0.8±0.1(8±1)
Laser unit Taptite cup S M3x8 SR 4 0.8±0.05(8±0.5)
Scanner earth plate
Taptite cup S M3x8 SR
(Fastening side of
scanner plate )
10.8±0.1(8±1)
Taptite cup S M3x8 SR
(LV shield plate side)
10.5±0.1(5±1)
LV shield plate cover
Taptite cup S M3x8 SR 3 0.5±0.1(5±1)
Taptite bind B M4x12 1 0.8±0.1(8±1)
Screw pan M4x8 1 0.5±0.1(5±1)
Inlet Taptite flat B M3x10 1 0.5±0.1(5±1)
Earth harness Screw pan M4x8 1 0.5±0.1(5±1)
Low-voltage power supply PCB
ASSY
Taptite cup S M3x8 SR 1 0.5±0.1(5±1)
Taptite bind B M4x12 2 0.8±0.1(8±1)
Under bar earth plate R Taptite cup S M3x8 SR 1 0.5±0.1(5±1)
Under bar
(Front right side)
Taptite bind B M4x12 1 0.8±0.1(8±1)
LV shield plate Taptite bind B M4x12 1 0.8±0.1(8±1)
Hold cover 1 Taptite bind B M4x12 1 0.8±0.1(8±1)
Toner LED PCB ASSY Taptite pan B M3x8 1 0.5±0.1(5±1)
Hold cover 2 Taptite bind B M4x12 2 0.8±0.1(8±1)
Under bar earth plate L Taptite cup S M3x8 SR 1
0.8±0.1(8±1)
Under bar
(Front left side)
Taptite bind B M4x12 1
Under bar (Rear side
(DCP-8250DN/MFC-8950DW/
8950DWT/8952DW/8952DWT
only)
Taptite bind B M4x12 2 0.8±0.1(8±1)
Main frame L ASSY
Taptite cup S M3x8 SR 3 0.8±0.1(8±1)
Taptite bind B M4x12 4 0.8±0.1(8±1)
Drive sub ASSY Taptite bind B M4x12 8 0.8±0.1(8±1)
Location of screw Screw type Q'ty
Tightening torque
N.m (kgf.cm)
