Main motor ASSY Taptite cup S M3x8 SR 4 0.8±0.1(8±1)
Main motor cover Taptite bind B M3x10 2 0.5±0.1(5±1)
MP solenoid Taptite bind B M3x10 1 0.5±0.1(5±1)
Main PCB shield calking ASSY Taptite bind B M4x12 4 0.8±0.1(8±1)
Duplex solenoid Taptite bind B M3x10 1 0.5±0.1(5±1)
Bottom frame L Taptite bind B M4x12 3 0.8±0.1(8±1)
Base plate
Taptite bind B M4x12 4 0.8±0.1(8±1)
Screw pan (S/P washer)
M3x12DB
20.45±0.05(4.5±0.5)
High-voltage power supply PCB
ASSY
Taptite bind B M4x12 2 0.8±0.1(8±1)
T1 paper feed actuator holder
ASSY
Taptite bind B M3x10 1 0.5±0.1(5±1)
Main frame R Taptite bind B M4x12 5 0.8±0.1(8±1)
MP feed frame Taptite bind B M3x10 2 0.5±0.1(5±1)
MP paper empty sensor PCB
ASSY
Taptite bind B M3x10 1 0.5±0.1(5±1)
T2 tray cover Taptite bind B M4x12 2 0.8±0.1(8±1)
T2 side cover L Taptite bind B M4x12 1 0.8±0.1(8±1)
T2 side cover R Taptite bind B M4x12 1 0.8±0.1(8±1)
T2 front cover ASSY Taptite cup S M3x8 SR 1 0.8±0.1(8±1)
Under bar (Two) Taptite bind B M4x12 4 0.8±0.1(8±1)
T2 frame R unit
Taptite cup S M3x8 SR 2 0.8±0.1(8±1)
Taptite bind B M4x12 2 0.8±0.1(8±1)
T2 paper feed frame unit Taptite cup S M3x8 SR 3 0.8±0.1(8±1)
T2 front beam Taptite bind B M4x12 2 0.8±0.1(8±1)
T2 paper feed actuator holder
ASSY
Taptite bind B M3x10 1 0.5±0.1(5±1)
T2 back cover Taptite bind B M4x12 2 0.8±0.1(8±1)
*1 South Korean models are not equipped with the earth plate, taptite cup S M3x8 SR screw,
and tapttite bind B M4x12 screw.
Location of screw Screw type Q'ty
Tightening torque
N.m (kgf.cm)
