Description
12/108 CLS Pro 600 – Line and Contrast Sensor
Application with EKR 1500 / CCD line guider as CCD 2004 replacement:
Sensor CLS Pro 600
with control panel
(from software version 1.8.1)
CAN – Module bus coupler
EKR 1500
CCD Line Guider
Fig.6: Application with EKR 1500 / CCD line guider as CCD 2004 replacement
2.4 Terms Used in this Manual
2.4.1 General Information
In principle, the windows displayed on the keyboard’s graphics
display are laid out as follows:
Fig.7: Display Layout
①
Status Bar
②
Footer
