Operation
6
CLS Pro 600 – Line and Contrast Sensor 65/108
Parameter Function / Meaning
dig. out reset
delay:
Use this parameter to set up the delay time
needed for resetting the digital outputs.
Setting Range: 0 – 9999 ms
Default Setting: 0 ms.
dig. out set delay:
Use this parameter to set up the delay time
needed for setting up the digital outputs.
Setting Range: 0 – 9999 ms
Default Setting: 0 ms.
mode digital out:
You can define which signal will be transmit-
ted from the digital outputs from here. Only
the guiding unlock and guiding lock settings
are available for these parameters at the mo-
ment.
guiding edge:
Use this parameter to define the edge that
will be used for the controlling. This para-
meter is only available for line scanning ap-
plications.
Setting Options:
▶ median of 1 and 2:
Standard setting. A median value will be cre-
ated using both edges of the line and this will
be generated as the control position.
▶ first edge:
It will be controlled by the left edge as dis-
played on the screen.
▶ second edge:
It will be controlled by the second edge.
▶ int. watchdog:
Not used at the moment.
Pre-Adjustment:
median of 1 and 2
6.7.1.3 \\configuration\remote control ekr\
remote control ekr:
The parameters for the controller’s remote control are set up in
this sub-menu.
Parameter Function / Meaning
internal W-Val:
Use this parameter to run a W-value internal
simulation. We recommend that the para-
meter is only activated in stand-alone mode,
as a controller is not used in this mode.
