Technical Data
9
CLS Pro 600 – Line and Contrast Sensor 85/108
9.1.6 Measuring Window Cover
■
Laminated safety glass with PVB film as per EN 1565 and EN 167
9.1.7 Control Panel Interface
Voltage:
24V DC (corresponds to the
power supply)
Current:
max. 0.5 A (protected by a poly-
fuse)
Bus Interface: 500k baud, no metallic isolation
Connection:
Plugged in from the outside us-
ing a 4-pin micro style M8 con-
nector
9.1.8 Weight / Dimensions
Weight:
Approx. 1.18 kgs (sensor
without control panel and
holder)
Dimensions: See chapter 9.2.5
9.2 Control Panel
9.2.1 Environmental Conditions
Working Temperature: 0 ... 45°C
Storage Temperature: - 10°C ... + 70°C
Working Humidity: 5 ... 90%, not condensing
Protection Type: IP 50
9.2.2 Power Supply
Voltage:
24V DC (power supplied by the
sensor)
9.2.3 Display
LCD TFT color graphics module:
Resolution:
320 x 240 pixels,
LED background lighting
9.2.4 Weight / Dimensions
Weight: approx. 0.26 kgs
Dimensions: See chapter 9.2.5
