84/108 CLS Pro 600 – Line and Contrast Sensor
9 Technical Data
9.1 Sensor
9.1.1 Environmental Conditions
Working Temperature: 0 ... 45°C
Storage Temperature: - 10°C ... + 70°C
Working Humidity: 5 ... 90%, not condensing
Protection Type: IP54
Operation Site:
In closed buildings
< 2000 m above sea level
External Light:
The sensor and control panel
should be protected from direct
sunshine
9.1.2 Power Supply
Voltage:
24 V DC ± 10 % (including
ripple)
Power Consumption:
max. 0.5 A (including panel, 2 x
lights 100% switched on and 80
mA external outputs)
9.1.3 Digital Inputs
2 x digital inputs with metallic separation for path cycle / reset:
Input Resistance: 4.7 kOhm each
Switching Threshold:
< 4V (low), > 8V (high); switch-
ing sensor can be used for ”+“
only (pnp)
9.1.4 Digital Outputs
■ 1x error output, switched against +24V
■ 1x external light switched against +24V
■ 1x external light, trigger output, +12V / 5 mA
■ both external light outputs have a joint load rating of 80 mA
9.1.5 Analogue Output
■ 1 x analogue output 0 - 10V, 5 mA
■ Not protected against external overvoltage / polarity reversals
