Operation
6
CLS Pro 600 – Line and Contrast Sensor 45/108
6 Operation
6.1 General Information
If the sensor will be used an integral part of a projected BST eltro-
mat system then the standard configuration has already been
completed. However, the onsite set-up (line or edge) still has to
be undertaken. If required or if necessary, you can:
Create a quick menu
Create and save a job specific configuration.
The procedure for this part is given in Section 6.5 Standard opera-
tion.
If the sensor is changed onsite (with or without the panel) then a
new component optimisation is required. Parameter settings
might have to be remade. Optimising the specific parameters and
their significance are described in Section 6.6 Expanded operation.
6.2 Operating Display
The CLS Pro 600 screen display depends on the mode that the
sensor will be working in. We differentiate between setup mode
and scanning mode. The menu can be called up from either
mode. However, access to the specific sub-menus is differs.
6.2.1 Setup Mode Display Window
The sensor settings are made via the guiding job in setup mode.
The parameters needed for the setting up will be displayed using
graphic symbols and numerical values on the control panel screen.
You will find the meaning for the individual symbols in the follow-
ing illustration.
