Buell S1 Lightning User Manual

3-47
7. Install valve tappets and push rods. See VALVE TAP-
PETS, INSTALLATION on page 3-39.
8. Install ignition system. See Section 7.
9. Install any components removed to gain access to gear-
case (i.e. exhaust system components, air cleaner, etc.).
Figure 3-63. Gearcase Cover Mounting Screw
Torque Sequence
b0064a3x
7
3
1
11
10
9
4
2
5
6
8

Buell S1 Lightning Specifications

General

Transmission	5-speed
Rear Brakes	Single 230mm disc, single-piston caliper
Compression Ratio	10.0:1
Ignition	Electronic
Engine Type	Air-cooled, four-stroke, 45° V-twin
Rear Suspension	Showa monoshock, adjustable preload, compression and rebound damping
Front Brakes	Single 340mm disc, 6-piston caliper
Seat Height	775 mm
Bore x Stroke	88.8 mm x 96.8 mm
Fuel System	Carburetor
Frame	Tubular steel
Tires	Front: 120/70 ZR17, Rear: 170/60 ZR17
