6-1
SPECIFICATIONS
*Final gear ratios indicate number of mainshaft revolutions
required to drive output sprocket one revolution.
**Overall gear ratios indicate number of engine revolutions
required to drive rear wheel one revolution.
TRANSMISSION
Transmission Type 5 forward speed, foot shift
Clutch Type Wet – multiple disc
Clutch fluid capacity 1.0 quart 0.95 liter
Fluid part no.-quart 98854-96
Fluid part no.-gallon 98855-96
TRANSMISSION GEAR RATIOS FINAL* OVERALL**
First (Low) Gear 2.69 9.717
Second Gear 1.97 7.118
Third Gear 1.43 5.180
Fourth Gear 1.18 4.269
Fifth (High) Gear 1.00 3.615
PRIMARY DRIVE (ENGINE-TO-TRANSMISSION)
Engine sprocket 35 teeth
Clutch sprocket 56 teeth
Ratio 1.60: 1
FINAL DRIVE (TRANSMISSION-TO-REAR WHEEL)
Transmission sprocket 27 teeth
Rear wheel sprocket 61 teeth
Secondary drive belt 128 teeth
Ratio 2.26:1
6
NOTE
Service wear limits are given as a guideline for measuring components that are not
new
. For measurement specifications not
given under SERVICE WEAR LIMITS, see NEW COMPONENTS.
CLUTCH PLATE
THICKNESS
NUMBER
REQUIRED
NEW COMPONENTS SERVICE WEAR LIMITS
IN. MM IN. MM
Friction plate (fiber) 8 0.0866 + 0.0031 2.200 + 0.079 0.006 0.15
Steel plate 6 0.0629 + 0.0020 1.598 + 0.051 0.006 0.15
Clutch pack
0.661
minimum
16.79
minimum
