Buell S1 Lightning User Manual

6-14
TRANSMISSION
GENERAL
See Figure 6-11. The transmission is a five-speed constant-
mesh type housed in an extension of the crankcase. The
transmission permits the rider to vary the ratio of engine
speed-to-rear driving wheel speed in order to meet the vary-
ing conditions of operation.
The transmission is foot-operated by the gear shifter lever,
which transmits the force through a gear shifter shaft. The
shifter shaft actuates a pawl and a shifter fork drum. The
shifter fork drum moves shifter forks, which slide a series of
shifter clutch gears, on the mainshaft and countershaft, into
and out of mesh with the other gears.
LUBRICATION
Drain transmission and refill to correct level with fresh, clean
lubricant at least once each year or every 5000 miles (8000
km), whichever comes first. For best results, drain lubricant
while hot.
See CLUTCH, TRANSMISSION FLUID in Section 1 for more
information.

Buell S1 Lightning Specifications

General

Transmission	5-speed
Rear Brakes	Single 230mm disc, single-piston caliper
Compression Ratio	10.0:1
Ignition	Electronic
Engine Type	Air-cooled, four-stroke, 45° V-twin
Rear Suspension	Showa monoshock, adjustable preload, compression and rebound damping
Front Brakes	Single 340mm disc, 6-piston caliper
Seat Height	775 mm
Bore x Stroke	88.8 mm x 96.8 mm
Fuel System	Carburetor
Frame	Tubular steel
Tires	Front: 120/70 ZR17, Rear: 170/60 ZR17
