Buell S1 Lightning User Manual

6-15
Figure 6-11. Transmission Power Flow
413 25 413 25
41325
41325413 25
41325
Neutral
– Power flow
– Sliding member
Countershaft
Mainshaft
Out
1st Gear
Countershaft
Mainshaft
In
2nd Gear
Countershaft
Mainshaft
In
3rd Gear
Countershaft
Mainshaft
Out
In
5th Gear
Countershaft
Mainshaft
Out In
4th Gear
Countershaft
Mainshaft
In Out
XLH transpower flow

Buell S1 Lightning Specifications

General

Transmission	5-speed
Rear Brakes	Single 230mm disc, single-piston caliper
Compression Ratio	10.0:1
Ignition	Electronic
Engine Type	Air-cooled, four-stroke, 45° V-twin
Rear Suspension	Showa monoshock, adjustable preload, compression and rebound damping
Front Brakes	Single 340mm disc, 6-piston caliper
Seat Height	775 mm
Bore x Stroke	88.8 mm x 96.8 mm
Fuel System	Carburetor
Frame	Tubular steel
Tires	Front: 120/70 ZR17, Rear: 170/60 ZR17
