INTELLIDOX DOCKING MODULE USER MANUAL || PREPARE MODULES FOR USE
BW TECHNOLOGIES BY HONEYWELL PAGE 35 OF 103
Connect a Calibration Gas Cylinder
The IntelliDoX Enabler Kit includes tubing and quick connect fittings that are appropriate
for use with calibration gas cylinders that are approved for use with this product. For best
results, BW Technologies recommends that the tubing is between 39 inches (1 meter) and
33 feet (10 meters) in length for calibration gas cylinders.
Before You Begin
1. Read and understand the warnings and cautions in this section.
2. Verify that you are in a normal atmosphere (20.9% v/v O
2
) that is free of hazardous
gas.
3. Verify that the end plate is attached and the latch arm is lowered and locked.
4. Verify that the exhaust tubing is connected, and that it is free of defects and
obstructions.
The maximum recommended calibration tubing length is 10 meters (33 feet). Use of
tubing that is longer than the recommended length may result in inaccurate or failed
compliance tests or calibrations.
A demand flow regulator must be used with all calibration gas cylinder connections.
The module inlet should not be pressurized.
The use of calibration gas cylinders other than those specified by BW Technologies
may result in unsafe calibration or possible non-recoverable failure of the equipment,
and will invalidate the warranty.
Do not use calibration gas cylinders past their expiration date.
Ensure that all calibration gas cylinders are in good condition.
Ensure that all calibration gas cylinders contain enough gas.
This equipment uses potentially harmful gas for calibrations. The equipment must be
attached to a venting system or be used in a well-ventilated area.
