INTELLIDOX DOCKING MODULE USER MANUAL || DETECTOR OPERATIONS
BW TECHNOLOGIES BY HONEYWELL PAGE 55 OF 103
Transfer Datalogs from a Detector
There are two ways to transfer datalogs from a detector to the module:
1. Manually, via the module operations menu, or
2. Automatically, by configuring detector settings via Fleet Manager II software.
Transferring Datalogs via the Detector Operations Menu
1. Insert a compatible detector into the module. Detector identification is displayed on
the LCD. After the detector is recognized, procedures specified to occur automatically
on insertion are performed.
2. When the module is configured to transfer datalogs on insertion, the datalogs are
transferred after other procedures specified to occur automatically on insertion are
completed. Go to step 5.
3. When the module is NOT configured to transfer datalogs on insertion, What do you
need to do? is displayed after the detector is recognized. Go to step 4.
4. Press or to select Transfer datalogs from my detector, and then press . If
the procedure is passcode-protected, then enter the passcode and press to
continue. The LCD changes to yellow. A progress bar and the Datalog file transfer
message are displayed.
5. When the transfer is complete, the LCD changes to green and Datalog transfer
complete is displayed. Press to continue.
6. Open the lid and remove the detector, or perform other procedures.
Transferring Datalogs Automatically by Configuring Settings via Fleet
Manager II Software
For more information about creating and transferring configuration settings files via Fleet
Manager II software, refer to Configure Module and Detector Settingson page 60. For
more information about configuring settings via Fleet Manager II software, refer to the
Fleet Manager II operator manual.
