INTELLIDOX DOCKING MODULE USER MANUAL || CONFIGURE SETTINGS VIA FLEET MANAGER II SOFTWARE
BW TECHNOLOGIES BY HONEYWELL PAGE 62 OF 103
6. Verify that the configuration settings are updated.
5. Repeat steps 3 through 6 until configuration settings are verified for all modules.
Transferring the Configuration File to a Module via USB Flash Drive
For connected modules, transfer the configuration file to each appropriate
module in the gang.
1. Insert a USB flash drive into a USB port on your PC. Use Windows Explorer or My
Computer to open the USB flash drive, and then create a new folder named System.
2. Create the configuration file. See Creating a Configuration File via Fleet Manager
II on page 60.
3. Click Save to File. The Save Settings to File dialog box is displayed.
4. Save the configuration file to the System folder on the USB flash drive. Do not
change the file name or extension. Eject the USB flash drive from the PC.
5. Insert the USB flash drive into the USB port on the module. The USB File Copy
Utility menu is displayed. Press or to select Copy to dock and then press to
continue.
6. The LCD changes to yellow. A progress bar and alternating Do not remove stick
and USB transfer in progress messages are displayed while the file is transferred.
7. After the transfer is successfully completed, the LCD changes to blue and the
USB File Copy Utility menu is displayed. Press or to select Exit and then
press to continue.
8. The LCD changes to green. Remove the USB flash drive from the port when
prompted.
Transferring Configuration Settings to a Detector
1. Insert a compatible detector into the module. Detector identification is displayed on
the LCD.
2. If the detector is configured to update settings on insertion, then the detector settings
are updated automatically after the detector is recognized.
3. After the configuration update is completed, other procedures specified to occur on
insert are performed.
4. After all procedures are performed, remove the detector from the module and verify
that the configuration settings are updated. For more information, refer to the
appropriate detector operator manual.
