INTELLIDOX DOCKING MODULE USER MANUAL || REPLACE DETECTOR CRADLE AND CALIBRATION INSERT
BW TECHNOLOGIES BY HONEYWELL PAGE 79 OF 103
Replace Detector Cradle and Calibration Insert
This section contains information and instructions related to replacing an IntelliDoX detector cradle and calibration
insert.
Contents
Replace Detector Cradle and Calibration Insert ........................................................................................ 79
Upgrade the IntelliDoX to Fit Compatible Detectors ........................................................................ 79
What You Need to Replace the Detector Cradle and Calibration Insert .......................................... 79
Replace the Detector Cradle ....................................................................................................................... 80
Replace the Calibration Insert ..................................................................................................................... 82
Upgrade the IntelliDoX to Fit Compatible Detectors
The IntelliDoX system is designed for users to upgrade their detector docking solution to
meet their changing needs. The IntelliDoX allows users to upgrade from one detector to
another with the replacement of the detector cradle and calibration insert.
What You Need to Replace the Detector Cradle and Calibration Insert
A Philips screwdriver to remove the screws on the IntelliDoX
IMPORTANT: You must transfer data files from the IntelliDoX before you replace the
cradle and calibration insert.
Here's what you'll do to replace the cradle and calibration insert:
1. Transfer data from the IntelliDoX (see Transfer Data Files on page 71).
2. Update the firmware on the IntelliDoX to a compatible version, if required (see Update
Firmware on page 74).
3. Replace the cradle on the IntelliDoX.
4. Replace the calibration insert on the IntelliDoX.
