Canon IMAGECLASS LBP654CDW - Multi-Purpose Tray

Multi-Purpose Tray
1648-02C
LBP654Cdw LBP612Cdw
Paper guides
Adjust the paper guides to exactly the width of the loaded paper to ensure that paper is fed straight into the
machine.
For LBP654Cdw
● Press the lock release levers that are marked with arrows in the illustrations to release the locks and slide
the paper guides.
Paper tray
Pull out the paper tray when loading paper.
LINKS
Loading Paper in the Multi-Purpose Tray(P. 134)
Basic Operations
94
