Handling rolls

Selecting the Roll as the Paper Source

Y ou can switch between manual and auto paper feed methods by pressing the Feeder Selection button. The

Auto Feed lamp is lit when paper is supplied automatically , and the Paper T ray lamp is lit for sheets.

Y ou must specify the auto paper feed method when using rolls. Press the Feeder Selection button to

activate the Auto Feed lamp (a).

Caution

• Paper jams may occur if you load paper other than the paper specied in the paper settings for the

media source.

Note

• Y ou cannot switch the paper source in the following situations:

• If the Message lamp is ashing

Check the message on the Display Screen and take action as necessary . ( → P .696)

• If the Data lamp is ashing

Select the paper source after printing.

• If a printer menu operation is in progress

Select the paper source after the menu operation.

• When in the process of loading paper

Finish loading the paper before selecting the paper source.

• When in the process of replacing Ink T anks

Finish replacing the Ink T anks before selecting the paper source.

• If the T op Cover is open

Close the T op Cover before selecting the paper source.

At this point, load the roll. ( → P .124)

Note

• If any paper is loaded that will not be used, remove it before loading the roll.

( → P .128)

( → P .176 )

120 Handling Paper
