Canon imagePROGRAF iPF610 User Manual

The printer stops during a print job
The printer stops during a print job
An error message is shown on the Display Screen
Status Corrective Action
An error message is displayed during printing. Check the error message and take action as
necessary .
( → P .698)
The last portion of roll paper was used during a print
job, and paper could not be fed because the trailing
edge was taped to the roll.
Remove the portion of roll paper that was used and
insert a new roll.
( → P .128)
( → P .123)
( → P .82)
The printer ejects blank, unprinted paper
Status Corrective Action
The leading edge of the roll paper was cut to
straighten it.
This operation is normal.
The printer cuts the leading edge of the roll to
straighten it and ejects the scraps when T rim
Edge First in the printer menu is On or when T rim
Edge First is Automatic and the leading edge is
slanted. The printer is ready to print after this initial
preparation.
When Off is selected under T rim Edge First , the
edge is not cut and scraps are not removed.
The Printhead nozzles are clogged. Print a test pattern to check the nozzles and make
sure the Printhead is in good condition for printing.
( → P .625)
Clean the Printhead if the nozzles are clogged.
( → P .626)
A print job was received from an incompatible printer
driver .
Use the correct imagePROGRAF printer driver for
the printer and try printing again.
The printer is damaged. Contact your Canon dealer for assistance.
664 T roubleshooting

Canon imagePROGRAF iPF610 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Magenta, Pigment cyan, Pigment magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Media thickness	1.5 mm
Maximum print size	610 x 1897 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Maximum printable area	203 mm
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Compatible ink types, supplies	PFI-101 (130ml, C, M, Y, PC, PM, R, G, B), PFI-103 (130ml, BK, MBK, GY, PGY)
Display	LCD
Sound power level (standby)	35 dB
Sound pressure level (printing)	49 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10base-T; 100base-TX Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPX/SPX (Netware 3.2(J), 4.1 (J), 4.11(J), 4.2(J), 5.0(J), 5.1(J) SNMP (Canon-MIB), HTTP, TCP/IP, AppleTalk
Package weight	77000 g
Bundled software	imagePROGRAF Printer Driver 2007 (Win/Mac), imagePROGRAF Status Monitor Media Configuration Tool Print Plug-in f/ Photoshop Print Plug-in f/ Digital Photo Pro Digital Photo Front-Access
Power consumption (standby)	6 W
Power consumption (typical)	100 W
Power consumption (PowerSave)	1 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows 2000, XP, Vista 32 bit/64 bit Macintosh OS 9, OS 10, Leopard
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Size (imperial)	24 \
Dimensions (WxDxH)	1177 x 670 x 348 mm
