Canon imagePROGRAF iPF610 User Manual

Windows
Page Setup Sheet (W indows)
The following settings are available on the Page Setup sheet. For details on settings items, refer to the
printer driver help.
Setting Item Description
A Page Size
Select the page size as specied in the source application.
For details on available page sizes, see “Paper Sizes”. (→P .1 17)
B Borderless Printing Borderless printing is available if Roll Paper is selected in the L Media
Source list. Choose from the following options when this setting is
activated.
Borderless Printing on Paper of Equivalent Size (→P .327)
Borderless Printing by Resizing Originals to Fit the Roll Width (→P .329)
Borderless Printing at Actual Size (→P .309)
D Fit Media Size Scales the document image to match the paper size.
E Scale to t Roll Paper
W idth
Scales the document image to match the roll width.
F Print Image with Actual
Size
Prints documents at their actual size. This function is available, when you
have selected the size same as the width of Roll Paper for either length
or width of the document from the A Page Size list.
G Media Size
A vailable when Fit Media
Size is selected.
Choose the size of the paper you will print on.
For details on available paper sizes, see “Paper Sizes”. (→P .1 17)
Paper sizes compatible with borderless printing are shown in the list.
C Enlarged/Reduced Printing
Choose from the following options when this setting is activated.
Resizing Originals to Match the Paper Size (→P .272)
Resizing Originals to Fit the Roll Width (→P .273)
Resizing Originals by Entering a Scaling V alue (→P .274)
D Fit Media Size Scales the document image to match the paper size.
E Fit Roll Paper W idth Scales the document image to match the roll width.
F Scaling Resizes the document image based on a specied scaling value. Enter a
value in a range of “5-600.”
G Media Size
Choose the size of the paper you will print on.
For details on available paper sizes, see “Paper Sizes”. (→P .1 17)
Software 479

Canon imagePROGRAF iPF610 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Magenta, Pigment cyan, Pigment magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Media thickness	1.5 mm
Maximum print size	610 x 1897 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Maximum printable area	203 mm
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Compatible ink types, supplies	PFI-101 (130ml, C, M, Y, PC, PM, R, G, B), PFI-103 (130ml, BK, MBK, GY, PGY)
Display	LCD
Sound power level (standby)	35 dB
Sound pressure level (printing)	49 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10base-T; 100base-TX Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPX/SPX (Netware 3.2(J), 4.1 (J), 4.11(J), 4.2(J), 5.0(J), 5.1(J) SNMP (Canon-MIB), HTTP, TCP/IP, AppleTalk
Package weight	77000 g
Bundled software	imagePROGRAF Printer Driver 2007 (Win/Mac), imagePROGRAF Status Monitor Media Configuration Tool Print Plug-in f/ Photoshop Print Plug-in f/ Digital Photo Pro Digital Photo Front-Access
Power consumption (standby)	6 W
Power consumption (typical)	100 W
Power consumption (PowerSave)	1 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows 2000, XP, Vista 32 bit/64 bit Macintosh OS 9, OS 10, Leopard
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Size (imperial)	24 \
Dimensions (WxDxH)	1177 x 670 x 348 mm
