Printing banners or at other non-standard sizes

10. Close the printer driver dialog box.

Note

• Y ou can also specify a Custom Size as the paper size. Note that Custom Size settings are not

available after you exit the application.

For more information, see “Printing on Non-Standard Paper Sizes (Windows)”. (→P .362)

Creating the banner in the application

Follow the steps below to create the banner in Microsoft W ord using the Custom Media Size you registered.

1. Start Microsoft W ord.

2. Choose Page Setup from the File menu to display the Page Setup dialog box.

3. Under Paper Size , click the Custom Media Size you registered-"My Horizontal Banner" in this

example.

Important

• If "My Horizontal Banner" is not listed, make sure this printer is selected as the printer to use.

• In applications such as Microsoft PowerPoint that do not enable you to choose registered paper

sizes, use the custom paper size setting in “Custom” and specify 100×500 mm (3.9×19.7 in)

4. Set the printing orientation to horizontal.

5. Create the banner .

Printing the banner

Follow the steps below to print the banner using the corresponding banner settings.

1. Choose Print in the Microsoft W ord menu.

2. Select the printer in the dialog box, and then open the printer driver dialog box. ( → P .494)

3. Make sure the Main sheet is displayed.

4. In the A Media T ype list, select the type of paper that is loaded. In this case, click Plain Paper .

5. After conrming that D Easy Settings is selected, click POP Ad in the E Print T arget list.

372 Enhanced Printing Options

Other manuals for Canon imagePROGRAF iPF610

Questions and Answers:

Need help?

Do you have a question about the Canon imagePROGRAF iPF610 and is the answer not in the manual?

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Magenta, Pigment cyan, Pigment magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Media thickness	1.5 mm
Maximum print size	610 x 1897 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Maximum printable area	203 mm
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Compatible ink types, supplies	PFI-101 (130ml, C, M, Y, PC, PM, R, G, B), PFI-103 (130ml, BK, MBK, GY, PGY)
Display	LCD
Sound power level (standby)	35 dB
Sound pressure level (printing)	49 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10base-T; 100base-TX Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPX/SPX (Netware 3.2(J), 4.1 (J), 4.11(J), 4.2(J), 5.0(J), 5.1(J) SNMP (Canon-MIB), HTTP, TCP/IP, AppleTalk
Package weight	77000 g
Bundled software	imagePROGRAF Printer Driver 2007 (Win/Mac), imagePROGRAF Status Monitor Media Configuration Tool Print Plug-in f/ Photoshop Print Plug-in f/ Digital Photo Pro Digital Photo Front-Access
Power consumption (standby)	6 W
Power consumption (typical)	100 W
Power consumption (PowerSave)	1 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows 2000, XP, Vista 32 bit/64 bit Macintosh OS 9, OS 10, Leopard
Sustainability certificates	ENERGY STAR
