Canon imagePROGRAF iPF610 User Manual

Mac OS X
Main Pane (Mac OS X)
The following settings are available on the Main pane. For details on settings items, refer to the printer
driver help.
Note
• On the Main pane, choose Easy Settings to specify basic print settings based on the print target, or
switch to Advanced Settings to complete more detailed settings as desired.
Conguration using Easy Settings
Setting Item Description
A Media T ype
Select the paper type.
For information on the types of paper the printer supports, refer to the Paper
Reference Guide . ( → P .1 12)
B Get
Information
Click to display the Get Information dialog box, which shows media types specied
on the printer for each media source. When you select a media source, your
selection is applied to the printer driver settings for the media source and media
type.
C Set
Click to display the Media Detailed Settings dialog box for ink drying time and
other detailed settings based on the paper type.
E Print T arget Choose presets that match the type of document to be printed.
Printing Photos and Images (Mac OS X) (→P .209)
Printing Line Drawings and T ext (Mac OS X) (→P .212)
Printing Of ce Documents (→P .213)
F V iew set. Click to display the V iew settings dialog box, which enables you to conrm the
settings for the selected item from the E Print T arget list or change the order of
items listed in E Print T arget .
L Printer Click to display the Printer dialog box, which indicates the ink levels and gives
other information about the printer .
Software 519

Canon imagePROGRAF iPF610 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Magenta, Pigment cyan, Pigment magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Media thickness	1.5 mm
Maximum print size	610 x 1897 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Maximum printable area	203 mm
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Compatible ink types, supplies	PFI-101 (130ml, C, M, Y, PC, PM, R, G, B), PFI-103 (130ml, BK, MBK, GY, PGY)
Display	LCD
Sound power level (standby)	35 dB
Sound pressure level (printing)	49 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10base-T; 100base-TX Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPX/SPX (Netware 3.2(J), 4.1 (J), 4.11(J), 4.2(J), 5.0(J), 5.1(J) SNMP (Canon-MIB), HTTP, TCP/IP, AppleTalk
Package weight	77000 g
Bundled software	imagePROGRAF Printer Driver 2007 (Win/Mac), imagePROGRAF Status Monitor Media Configuration Tool Print Plug-in f/ Photoshop Print Plug-in f/ Digital Photo Pro Digital Photo Front-Access
Power consumption (standby)	6 W
Power consumption (typical)	100 W
Power consumption (PowerSave)	1 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows 2000, XP, Vista 32 bit/64 bit Macintosh OS 9, OS 10, Leopard
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Size (imperial)	24 \
Dimensions (WxDxH)	1177 x 670 x 348 mm
